Anodizing Production Line
>
3000T/Month Horizontal U Mode Anodizing Production Line with 6500mm Max Profile Length Aluminum Anodizing Line

3000T/Month Horizontal U Mode Anodizing Production Line with 6500mm Max Profile Length Aluminum Anodizing Line

Brand Name: MEI-AL
Model Number: APL-3000T
MOQ: 1set
Price: RMB30,000,000-50,000,000/set
Packaging Details: Export Stander Packing
Payment Terms: T/T
Detail Information
Place of Origin:
CHINA
Output:
3000T/month
Mode:
Horizontal
Operation Mode:
Semiautomatic Or Automatic
Anodizing Film Thickness:
8-12µm
Max Profile Length:
6500mm
Colour:
Silver Bronze Brown Black Champagne Gold
Tanks Inside Size:
8000*width*3500
Voltage:
380V~415v
Supply Ability:
1set/6 months
Highlight:

Power Anodizing Production Line

,

Anodizing Production Line Process

Product Description
Equipment Overview

The 3000T/month horizontal U-mode anodizing production line is a semi-automatic or fully automatic system designed for high-volume aluminium profile finishing. It combines a manual racking system with a controlled horizontal U-shaped tank layout to deliver consistent anodized film thickness of 9–12 µm across profiles up to 6500 mm in length.

  • Equipment name: Control Horizontal Anodizing Line
  • Output: 3000 T/month
  • Model: Horizontal U mode
  • Operation style: Semi-automatic or automatic
  • Racking method: Manual racking system
Design Conditions
Parameter Specification
AlloyAluminium 6061 to 6063 or others
Anodizing film thickness9–12 µm
Average coverage area350 m²/T (ton)
Max aluminium profile length6500 mm
Extrusion ratio2.5 kg/m²
Working hours per month300 d/m × 20 h/d = 600 h/m
Racking systemThree fixtures per rack
Racking operationManual
Equipment usage rate0.9
Power supplyAC 3-phase 380 V, 50 Hz
Control powerAC 220 V, 50 Hz
Water supply2 kg/cm²·G
Hot steam6 kg/cm²·G
Compressor air6 kg/cm²·G
Process Tanks
Stage Bath Composition Tanks
Degreasing Free sulfuric acid 180 ± 30 g/L 1
Alkaline Etching Free alkali 40–60 g/L, Al³⁺ 30–120 g/L 2
Neutralization Free sulfuric acid 180 ± 20 g/L 1
Anodizing Free sulfuric acid 140–180 g/L, Al³⁺ ≤ 20 g/L 8
Colouring Stannous sulfate 3–8 g/L, free sulfuric acid 15–25 g/L, pH 0.8–1.2 3
Medium Temperature Sealing pH 5–6.5, nickel ion 0.8–1.3 g/L, fluoride ion 0.3–0.7 g/L 3
Treatment Process
1. Degreasing
  • 6 jig (rack) / tank × 1 tank = 6 jig (rack)
  • Treatment time: 2–5 min
2. Alkaline Etching
  • 6 jig (rack) / tank × 2 tanks = 12 jig (rack)
  • Treatment time: 3–15 min
3. Neutralization
  • 6 jig (rack) / tank × 1 tank = 6 jig (rack)
  • Treatment time: 1–5 min
4. Anodizing
  • 3 jig (rack) / tank × 8 tanks = 24 jig (rack)
  • Current density: 130 A/m²
  • Process time: 26 min
  • Unprocess time: 7 min
  • Total time: 26 + 7 = 33 min
  • Average anodizing layer: 0.36 × 1.3 × 26 × 0.77 = 9.4 µm
5. Colouring
  • Colour process: mixed salts
  • Quantity: 3 jig (rack) / tank × 1 tank = 3 jig (rack)
  • Current density: 70 A
  • Process time: 2–8 min
6. Sealing
  • Sealing method: medium or normal temperature sealing
  • Quantity: 6 jig (rack) / tank × 1 tank
  • Process time: 10–15 min
Design Parameters & Capacity Settings
Anodizing Treatment Area
  • Each anodizing process tank requires 33 min; total jig (rack) per year: (3 rack × 8 tanks × 60 min/h) ÷ 33 min × 600 h = 26,181 jig (rack)
  • Design: 50 m² per jig (rack), where every tank is 100 m²
  • Area treatment per year: 26,181 jig (rack) × 50 m²/jig = 1,309,050 m²
Anodizing Treatment Weight
  • Monthly output: 1,309,050 m² ÷ 350 m²/T × 0.9 = 3,366 T ≥ 3,000 T
Power Consumption
  • Anodizing tank: 100 m²/tank × 130 A/m² ÷ 0.9 = 14,444 A/tank; power rectifier: 15,000 A = 3 units
  • Colouring tank: 100 m²/tank × 70 A/m² ÷ 0.9 = 7,777 A/tank; colour rectifier: 8,000 A = 3 units
Process Chart

Legend for the process flow diagram:

  • De Degreasing
  • Rs Rinsing
  • HW Rs Hot Water Rinsing
  • AE Alkaline Etching
  • Ne Neutralization
  • An Anodizing
  • Cl Coloring
  • Sl Sealing
  • MU Material Unloading
  • Pc Packing
Horizontal U-mode anodizing production line process flow chart showing degreasing, rinsing, alkaline etching, neutralization, anodizing, coloring, sealing, unloading and packing stages

Horizontal U-mode anodizing line process flow
